Sand Slurry Ball Mill Machine for AAC Block
Description
Main Parameter
| Model | Shell rotation speed(r/min) | Ball load(t) | Feeding size(mm) | Discharging size(mm) | Capacity | Motor power(kw) |
Weight(t) |
| (t/h) | |||||||
| Φ1200*4500 | 32.4 | 5 | <=25 | 0.074-0.4 | 1.6-5.8 | 55 | 13.8 |
| Φ1500*4500 | 27 | 11 | <=25 | 0.074-0.4 | 3-6 | 110 | 21 |
| Φ1500*5700 | 28 | 12 | <=25 | 0.074-0.4 | 3.5-6 | 130 | 24.7 |
| Φ1830*7000 | 24.1 | 23 | <=25 | 0.074-0.4 | 7.5-17 | 245 | 36 |
| Φ2200*7500 | 21.7 | 35 | <=25 | 0.074-0.4 | 12-25 | 380 | 56 |
| Φ2400*8000 | 21 | 40 | <=25 | 0.074-0.4 | 15-30 | 570 | 69 |
| Φ2700*8000 | 20.7 | 63 | <=25 | 0.074-0.4 | 18-40 | 710 | 122 |
| Φ3200*4500 | 18 | 65 | <=25 | 0.074-0.4 | 20-45 | 800 | 137 |
Feature
(1) Efficient and durable, simple structure, not easy to damage
(2) It is widely used for grinding sand, lime and mineral powder, and the fineness after grinding reaches 180-250 mesh
(3) It can grind dry or wet materials.
Advantage
(1) National standard steel is adopted to ensure material strength and wear resistance
(2) The shell adopts European standard plate rolling technology and automatic welding technology to ensure the running quality of the shell
(3) The size adopts heat treatment technology to ensure hardness and wear resistance
(4) The rotating system is mostly driven by bearings to ensure operation efficiency and reduce the traditional maintenance rate of bearing pads.
(5) Wide application and long service life
(6) 24-hour online service to eliminate service blind spots.
